Outdoor SSPA Ku-Band Range

Type Band Frequency (GHz) Output Input Size (mm) Weight Prime Power Datasheet

STS8/12/16KUFL

Ku

13.75 – 14.5

8W (Psat) 12W (Psat) 16W (Psat)

950 – 1700MHz

145H x 135L x 100W

2.75kg

36-72VDC
18-36VDC (optional)

PDF icon STS81216KuFL.pdf

STS16/20/25K

Ku

14.00 – 14.5
13.75 – 14.5

2W/5W16W (P1dB) / 20W (P1dB) / 25W (P1dB)

950 – 1450MHz
950 – 1700MHz

165H x 165L x 95W

2.5kg

90-265VAC 50-60GHz
or
36-72VDC

PDF icon Datasheet 16 20 25W Ku Band.pdf

STS40/50/60

Ku

14.00-14.50
13.75-14.50

40W (Psat) / 50W (Psat) / 60W (Psat)

950-1450MHz
950-1700MHz

165H x 165L x 94W

2.5kg

90-265VAC 50-60Hz or 36-72VDC 24-75VDC (Optional)

PDF icon STS-40-50-60W-Ku.pdf

STS80/100/125

Ku

14.00-14.50
13.75-14.50

80W (Psat) / 100W (Psat) / 125W (Psat)

950-1450MHz
950-1700MHz

345H x 215L x 100W

8kg

90-265VAC 50-60Hz 48VDC (Optional)

PDF icon STS-80-100-125W-Ku .pdf

STS150/200K

Ku

14.0 – 14.5
13.75 – 14.5

150W (Psat) / 200W (Psat)

950 - 1450MHz
950 – 1700MHz

390H x 225L x 110W
470H x 225L x 110W
(with output circulator)

12kg

90-265VAC 50-60Hz

PDF icon STS150-200K.pdf

STS 250/300/350/400K

Ku

14.0 – 14.5
13.75 – 14.5

250W (Psat) / 300W (Psat) / 350W (Psat)

950 - 1450MHz
950 – 1700MHz

460H x 345L x 280W

25kg

190-265VAC 50-60Hz

PDF icon Datasheet STS250 300W 350 400 Ku Band.pdf
